24V Tunable White LED Dimmable Driver Switch

LED Dimmable Driver Switch – CCT Tunable White 96W / 160W | Driver + Dimmer 2-in-1 | Constant Voltage | 24V | UL Listed Upgrade your tunable-white lighting system with our CCT LED Dimmable Driver Switch, an all-in-one solution that combines a constant-voltage LED driver, dimmer, and color-temperature controller in one compact unit. Designed specifically for CCT (Warm White + Cool White) LED strips, this driver allows smooth brightness dimming and precise color temperature adjustment from warm to cool white — without external controllers or compatibility issues. Backed by UL / cUL certification, active PFC, and high-frequency PWM output, this driver delivers stable, flicker-free performance for residential and professional lighting installations. Fully compatible with our Tunable White (CCT) LED Strips Key Features All-in-One Design: LED driver, dimmer, and CCT controller integrated in a single unit CCT Tunable White: Designed for Warm White + Cool White LED strips Constant Voltage Output for stable and reliable performance Smooth Flicker-Free Dimming: 0.3%–100% with 16 kHz PWM and gamma 2.2 curve Color Temperature Control: Seamless warm-to-cool white adjustment Built-In Dimmer: Preset control with ON/OFF switch 3-Way Switch Compatible for standard wall switch installations Fine Voltage Adjustment: Output voltage trim knob for precise calibration High Efficiency: Active PFC ≥ 0.99, low THD Certified & Safe: UL Listed, FCC, Class 2, SELV compliant Full Protection: Short circuit, overload, and over-temperature auto-recovery 5-Year Warranty Model Options 96W CCT LED Dimmable Driver Switch Output Voltage: 24V DC (adjustable approx. 24–26V) Input: 120V AC / 60Hz Rated Current: 4A Max Power: 96W Efficiency: ~91–92% Power Factor: ≥0.99 Use Cases: Under-cabinet lighting, slat wall panels, closets, shelving, accent walls 160W CCT LED Dimmable Driver Switch Output Voltage: 24V DC Input: 120V AC Max Power: 160W High-Power Version for Larger Loads Designed for: Long CCT LED runs, large wall installations, home theaters, commercial and architectural lighting Same CCT dimming, protection, and certification features as the 96W model (160W version follows the same SDD-CCT design architecture and control logic.) Environmental & Installation Operating Temperature: –40°C to +60°C Humidity: 20–95% RH (non-condensing) Cooling: Natural air convection Locations: Indoor, dry & damp rated Installation: Must be installed by a qualified professional  Ideal Applications Perfect for CCT tunable-white lighting, including: Slat wall LED lighting Under-cabinet & toe-kick lighting 3D wall panels with tunable white backlighting Closets & wardrobes Display shelves Home theaters Furniture & cabinetry integration Architectural accent lighting
