The Montrose – 1440 SF with Garage

Building: 30′ Wide x 32′ Long x 9.5′ x 14.5′ Off-Set Eave Height (19.5′ Peak) Alpine Combo-Building [6:12 pitch] 960 SF of living space 12″ Residential Gable & Eave Soffit Overhang Frame-outs include: (1) – 2630 window frame-out (1) – 1630 window frame-out (6) – 3040 window frame-outs (3) – 3068 pedestrian door frame-outs Garage: 22′ Wide x 20′ Long x 9.5′ Lower Eave x 12′-10″ Peak Height Sierra Single Slope Building [2:12 pitch] 440 SF of garage space (1) – 15.5’W x 7’H eave-side garage door frame-out Plus: 10′ Wide x 4′ Deep x 9′-6″ Eave Height Extension Cover 40 SF The New Haven Kit Includes: Complete frame system as described above, ready for assembly All wall and roof panels Complete trim package Kit does not include doors & windows, or any interior components. Shell kit only. Package Price: $39,387 package price 1,440 SF (interior. garage, and patio space) $27.35 PSF Customizations: The Montrose plan can be customized. Please inquire.
