Ozone PHOTON Sport Performance Paraglider

Ozone PHOTON Sport Performance Paraglider Sport Class 2-Liner Sport Performance+ – EN C The Photon brings near-competition class performance to experienced sport class pilots. All of Ozone’s 2-liner know-how has gone into designing this wing. A long development period with extensive prototyping and hundreds of hours of flying and safety testing has gone into this project, and we are very satisfied with the Photon’s “True Performance” in real XC conditions. The Photon represents the missing link between conventional 3-liners and high performance wings such as the Zeno2 and Enzo3. Based on the Zeno 2 Incredibly stable throughout the speed range in real XC conditions True 2-line design with intuitive rear riser control Near comp wing glide and speed performance For experienced Sport Class pilots Specifications Sizes XS S MS ML L XL Number of cells 71 71 71 71 71 71 Projected area (m2) 16.1 17.4 18.9 20.2 21.5 23.1 Flat Area (m^2) 19.1 20.7 22.3 23.9 25.5 27.3 Projected Span (m) 8.7 9.0 9.4 9.7 10.1 10.4 Flat Span (m) 11.1 11.6 12.0 12.5 12.9 13.3 Projected Aspect Ratio 4.7 4.7 4.7 4.7 4.7 4.7 Flat Aspect Ratio 6.5 6.5 6.5 6.5 6.5 6.5 Root Chord (m) 2.17 2.25 2.34 2.43 2.5 2.59 Glider Weight (kg) * 4.28 4.47 4.75 5 5.27 5.55 Certified Weight Range (kg) 60-75 70-85 80-95 90-105 100-115 110-130 Certification C C C C C C Wing weight may vary up to 50g per size due to slight variations in the manufacturing of the fabric used.   Colors The Design The Photon was developed from the Zeno 2. The aspect ratio is slightly lower, and the cell count is more moderate. We have also used a more inherently stable profile. By increasing the arc, several comfort and handling factors have been improved, and winglets have been added to compensate the effect of increased arc on roll stability and spiral behavior. The end result is the most accessible 2 liner we have ever developed. Character in Flight The Photon feels compact and solid throughout the speed range thanks to the stable profile, and the span & chordwise sail cohesion. It is trimmed for safety & ease of use, with great handling. The performance of the wing is immediately apparent – we have never flown an EN C wing with so much glide. It is a true 2-Liner wing, allowing the pilot direct angle of attack control throughout the speed range, which has safety benefits for experienced pilots and allows for higher average speeds whilst gliding in turbulent air. The rear riser control is intuitive and confidence inspiring. This wing is an ideal stepping stone for those new to this type of flying. Performance The glide performance is close to that of the Zeno 2 but the improved sail cohesion and lower aspect ratio makes it less demanding and more comfortable to fly. In terms of speed, it is the fastest EN C wing we have ever built, faster than the D4, M7 and Zeolite and the top speed is only slightly less than the Zeno2. Importantly it is solid and comfortable at these speeds and the winglets improve the roll stability for higher levels of efficiency in accelerated flight. Passive Safety Extensive in-house collapse testing by the Ozone R&D team has proven that the wing easily meets the safety requirements of the class, with side and frontal collapse behaviour very similar to the Delta 4. We don’t only test our wings in calm air, and the Photon is no exception. We have spent hundreds of hours pushing this wing hard, in real conditions, to confirm real life solidity and its true recovery from collapses, to ensure the wing is suitable for sport class pilots. The Pilot Certified EN C and available in six sizes, it is suitable for experienced pilots who have prior time flying EN C category wings and possess a high level of glider control skills with recent SIV experience. Package Contents Your OZONE wing is delivered standard with the following accessories: Special Folding Pillow, Concerto Light Folding Bag, Key Ring, Bottle Opener, Certificate of Authenticity, Two Sheets of White Sticky Cloth and Riser Bag. You may choose to add something to your order, such as: Glider Backpack, Easy Bag (quick stuff sack) or OZONE Clothing and Accessories. Materials Top Surface Cloth: Dominico N20D Bottom Surface Cloth: Porcher 7000E71 Rib cloth: Porcher 9017E29 (hard) / Porcher 7000E91 (hard) Upper lines: Edelrid 8001 & Edelrid 9200 Mid lines: Edelrid 8001 Lower Lines: Edelrid 8001 Downloads Manual: EN Manual: DE Manual: FR Manual: ES Rigging Diagram Line Chart Certification Documents Size XS Size S Size MS Size ML Size L Size XL
