ChamSys MagicQ Compact Wing

Overview: 10 Fader Playbacks 10 Execute Playbacks Full Colour Touch-Screen Attribute Display Connects to MQ50, M70, MQ80, MQ250M, MQ500, MQ500M and MQ500M+ Consoles Connects to MagicQ PC or MacOS Systems Upto 2 Compact Wings per System Separate Page/Up Down buttons USB Connection Dimmable Dual Colour Working Light Hardware Specifications: Fader Playbacks: 10 Executor Playbacks: 10 Total Number of Playbacks: 20 Touch-Screen Display: Yes Electronic Playback Legends: Yes USB Ports: 3 (1 USB-C In, 2 USB A Out) Kensington Security Lock Fixing: Yes Working Light Port: Yes Power Input: PowerCon True1 100-240 VAC Software Specifications (When used with PC Systems): Universes: 64 Max Number of DMX Channels: 32768 Max Number of Fixtures Supported: 32768 Max Number of Cues: 5000 Max Number of Cue Stacks: 2000 Max Number of Groups: 5000 Max Number of Palettes: 4096 Number of Media Server Layers Supported: 50 (Each different content) Included Accessories: USB A-C Cable: 1 Dual Colour Working Light: 1 Dust Cover: 1 PowerCon True1 Mains Cable: 1 Boxed Weights and Dimensions:: Length: 450mm (17.71 Inches) Width: 425mm (16.73 Inches) Height: 210mm (8.27 Inches) Weight: 5.5kg (12.13 Lbs) Wing Weights and Dimensions:: Length: 314mm (12.36 Inches) Width: 350mm (13.78 Inches) Height: 60mm (2.36 Inches) Weight: 4.0kg (8.82 Lbs) Flight Cased Weights and Dimensions:: Length: 486mm (19.13 Inches) Width: 404mm (15.9 Inches) Height: 214mm (8.43 Inches) Weight: 8.0kg (17.64 Lbs)
